Specifications
- Working Lenght: 3000mm
- Max Bending Lenght: 3000mm
- Max Thickness: 30mm
- Pre Bending: 25mm
- Upper and Under Axle: 400mm
- Side Axle: 300mm
- Motor Power: 22+22kw
- Bending Speed: 1.5 m\min
- Machine Size (Width / Lenght / Height): 2440*6500*2870mm
- Weight: 28000kg
Equipments
- Machine is steel construction.
- Spare control panel.
- Drop and Controlled from control panel in order to relaese easily bent metal sheet and Lifted upper rolls.
- Movement and parallelism adjustment of rollers controlled from control panel.
- Upper and Under Axle are driven with hydrolic motor and planetry gear box.
- Cone bending device.
- Digital display for both side axles with PLC.
